Single pole Winch Isolator Switch

Single pole Winch Isolator Switch

Enabling you to open or kill the power to you winch from one easy flick of a button on your dash.

No longer require manual isolators that have to be placed in view or around your driver’s seat.

These units can be placed anywhere on your vehicle and activated on or off via a 12v signal using small wire.

Non Latching

It requires a 12v signal on the 8mm spades to be switched into full contact.

When you remove the 12v signal the isolator will switch off and no longer make contact

A normal 2 way ON/OFF switch can be used for operating this type

Note: These isolators cannot be used with our DP/DT rocker switch.

Latching

They are latched on by a magnet so they draw no power when switched on or off.

The latching fucntion requires the 12v polarity on the 8mm spades to be switched over to change its state.

This means you only need a short 12v signal to change state

No longer need to have 12v constantly on the terminals to keep the Isolator on / connected.

Note: These isolators will need our DP/DT rocker switch.
